Magnador Sliding Driveway Gates
custom-built and engineered to last
Why choose a sliding driveway gate?
Space efficiency: Requires no swing arc, making them ideal for properties with limited driveway depth or steep inclines.
Automation-ready: Every Magnador sliding gate can be fitted with an automated motor and remote control.
Scalable: Handles large commercial and industrial openings where hinged alternatives become structurally impractical.
Perimeter security: Prevents an unguarded driveway, thereby removing the most common point of entry for opportunistic intruders.
Property value: A properly finished gate adds measurable resale value when potential buyers assess perimeter security.
Need A Quote?
"*" indicates required fields
Construction and materials
| Component | Magnador Specification | Why It Matters |
|---|---|---|
| Frame | 38mm × 38mm (under 4m) 50mm × 50mm (over 4m) |
Correct sizing prevents flexing and warping over time. |
| Infill bars | We cater for a large range of infills and designs. All gates come with a centre horizontal bracing. | Horizontal bracing prevents the common entry technique of bars being levered apart. |
| Galvanising | Hot-dip galvanised to highest quality standards. | Full hot-dipped galvanised coating protects against corrosion from the inside out. |
| Powder coat | Pure polyester powder coating. | Scratch, fade and weather resistant; suitable for coastal environments. |
| Hardware | Stopper brackets, top guide rollers, galvanised wheels, bottom tracks. | All-steel hardware. No nylon components that degrade in UV and heat. |
| Post | 76mm × 76mm or 100mm × 100mm, sunk 500mm in concrete. | Correctly embedded post essential for alignment and long-term function. |
Frame
Magnador Specification
38mm × 38mm (under 4m)
50mm × 50mm (over 4m)
Why It Matters
Correct sizing prevents flexing and warping over time.
Infill Bars
Magnador Specification
We cater for a large range of infills and designs. All gates come with a centre horizontal bracing.
Why It Matters
Horizontal bracing prevents the common entry technique of bars being levered apart.
Galvanising
Magnador Specification
Hot-dip galvanised to highest quality standards.
Why It Matters
Full hot-dipped galvanised coating protects against corrosion from the inside out.
Powder Coat
Magnador Specification
Pure polyester powder coating.
Why It Matters
Scratch, fade and weather resistant; suitable for coastal environments.
Hardware
Magnador Specification
Stopper brackets, top guide rollers, galvanised wheels, bottom tracks.
Why It Matters
All-steel hardware. No nylon components that degrade in UV and heat.
Post
Magnador Specification
76mm × 76mm or 100mm × 100mm, sunk 500mm in concrete.
Why It Matters
Correctly embedded post essential for alignment and long-term function.
Security features
Optional spear tops welded onto the upper frame make climbing difficult and uncomfortable for intruders.
Optional Doggy bars in the form of additional horizontal infills in the lower section prevent small animals and children from slipping beneath the gate and deny leverage points at ground level.
No visible or accessible fixing points: hardware is secured with UL 8 plugs and galvanised coach bolts, making removal or tampering significantly harder.
Automation options include keypads, intercom systems and sensor beams for access-controlled entry without compromising perimeter integrity.
Sizing guide
| Opening Width | Recommended Frame | Sliding Section |
|---|---|---|
| Up to 4 metres | 38mm × 38mm square tube | Equal to or greater than the opening width |
| 4 metres and over | 50mm × 50mm square tube | Equal to or greater than the opening width |
| Large commercial | Custom specification | Consult Magnador for an engineered solution |
Up to 4 Metres
Recommended Frame
38mm × 38mm square tube
Sliding Section
Equal to or greater than the opening width.
4 Metres and Over
Recommended Frame
50mm × 50mm square tube
Sliding Section
Equal to or greater than the opening width.
Large Commercial
Recommended Frame
Custom specification.
Sliding Section
Consult Magnador for an engineered solution.
Automation options
Remote control motor: Operate from inside your vehicle and the most popular choice for residential driveways.
Keypad entry: Code-based access for visitors or staff without issuing physical remotes.
Intercom with video: Verify visitors before granting access, integrated into your gate post.
Sensor beams: Prevent the gate closing on a vehicle or pedestrian, an important safety feature.
Home automation integration: Compatible with smart home systems for app control and scheduled access.
| Step | What We Do |
|---|---|
| 1. Site assessment | Measurement of opening, stacking space, ground condition and post-sinking depth requirements. |
| 2. Post installation | Support posts sunk approximately 500mm into concrete for structural stability. |
| 3. Track laying | Bottom tracks surface-fitted with a non-trip design for pedestrian safety. |
| 4. Gate hanging & alignment | Gate hung on steel rollers, adjusted for level travel; stopper brackets and top guides set. |
| 5. Motor fitment | Motor, remote receivers and access control hardware installed and tested (where specified). |
| 6. Sign-off & handover | Full operational test before handover; user guidance on maintenance and guarantee explained. |
1. Site Assessment
What We Do
Measurement of opening, stacking space, ground condition and post-sinking depth requirements.
2. Post Installation
What We Do
Support posts sunk approximately 500mm into concrete for structural stability.
3. Track Laying
What We Do
Bottom tracks surface-fitted with a non-trip design for pedestrian safety.
4. Gate Hanging & Alignment
What We Do
Gate hung on steel rollers, adjusted for level travel; stopper brackets and top guides set.
5. Motor Fitment
What We Do
Motor, remote receivers and access control hardware installed and tested (where specified).
6. Sign-off & Handover
What We Do
Full operational test before handover; user guidance on maintenance and guarantee explained.
| Task | Frequency | What to Do |
|---|---|---|
| Track cleaning | Monthly | Clear debris, leaves and stones from the bottom track. Blockages cause accelerated wheel wear. |
| Wheel & roller check | Every 3 months | Inspect for flat spots or binding. Use a dry lubricant, not grease as it attracts dirt. |
| Post & bolt inspection | Annually | Check the concrete footing for cracking or movement. Tighten all bolts. |
| Touch-up paintwork | As needed | Apply matching powder coat touch-up paint to chips before rust can establish. |
| Motor & remote service | Annually | Replace remote batteries, check the motor bracket and perform a software reset if behaviour changes. |
Track Cleaning
Frequency
Monthly
What to Do
Clear debris, leaves and stones from the bottom track. Blockages cause accelerated wheel wear.
Wheel & Roller Check
Frequency
Every 3 months
What to Do
Inspect for flat spots or binding. Use a dry lubricant, not grease as it attracts dirt.
Post & Bolt Inspection
Frequency
Annually
What to Do
Check the concrete footing for cracking or movement. Tighten all bolts.
Touch-up Paintwork
Frequency
As needed
What to Do
Apply matching powder coat touch-up paint to chips before rust can establish.
Motor & Remote Service
Frequency
Annually
What to Do
Replace remote batteries, check the motor bracket and perform a software reset if behaviour changes.
Expert consultation: We assess your site and recommend the correct product for your specific opening, exposure and security requirements.
Manufacture and installation: Every product is manufactured in our on-site facilities and installed by our own teams, ensuring quality control at every stage.
Automation and access control: Keypads, intercom systems, sensor beams and home automation integration are available at installation or can be retrofitted later.
Property value: A properly installed perimeter security system with documentation and guarantee adds measurable resale value to your property.
5-year free repair guarantee: All Magnador products are covered against manufacturing defects for five years.
Contact us to discuss options and availability in your region.
| Branch | Address | Telephone |
|---|---|---|
| Cape Town | 12, 21st Street (off Epping Ave), Elsiesriver Industrials | +27 21 931 0150 |
| Johannesburg | 94 Carter Street (off Forest Street), Forest Hill, Gauteng | +27 11 434 2625 |
| Durban | 44 Marcellin Drive, Nirvana Hills, Pinetown | +27 31 708 4594 |
Cape Town
Address
12, 21st Street (off Epping Ave), Elsiesriver Industrials
Telephone
+27 21 931 0150
Johannesburg
Address
94 Carter Street (off Forest Street), Forest Hill, Gauteng
Telephone
+27 11 434 2625
Durban
Address
44 Marcellin Drive, Nirvana Hills, Pinetown
Telephone
+27 31 708 4594
Frequently Asked Questions
Can I add a motor to an existing Magnador sliding gate?
Yes. All Magnador sliding gates are designed to accept a motor retrofit. The process typically takes half a day.
How long does installation take?
A standard residential sliding gate installation takes a couple days to allow for the concrete to set. Larger commercial gates or those requiring significant groundwork may take longer.
What happens if my gate is damaged or stops working?
All Magnador products are covered by a 5-year free repair guarantee. Contact your nearest branch and we will assess and repair the fault.
Can I choose the colour and design of my gate?
Yes. Magnador offers a range of powder coat colours and infill designs, including doggy bars, spear tops, solid panels and custom configurations. Clarify your requirements at the time of quoting.
What is the difference between a 38mm and 50mm frame?
Frame sizing is determined by gate width. Gates narrower than 4000mm are built on a 38mm x 38mm frame; gates wider than 4000mm require a 50mm x 50mm frame to prevent flexing over time.
